Chain Block 1Tx6M
- All Sunny Lifting chain blocks are manufactured and proof tested to AS1418.2.
- Fitted with 100% proof tested electrostatic black coating G80 alloy chain.
- Lightweight and low headroom design allow being easily transported and used in confined spaces.
- Stainless steel riveted tag suitable for underground mining application.
- Upper and lower hooks feature extra-wide throat openings to allow for easier attachment to loads.
- Robust cast hook latch provides durability and secures the load engagement.
- Double Pawl Mechanism provides a longer working life.
- Needle roller bearing allows hook swivel 360° for faster positioning.
- Three raised points on the hook allow operators to measure the hook to detect overload or deformation.
- Standard height of lift is 3 and 6 metres. Individually serial numbered with a test certificate and instruction manual supplied.
- Capacity: 1T
- Standard Lift Height: 6M
